ServoStep™ UL recognized and CSA certified integrated stepper motors up to 12 Nm with NEMA34 86x86mm flange
PRESS release: April 2024
Birkerød, Denmark - JVL A/S, one of the world’s leading producers in the field of integrated servo and stepper motors, proudly announces that the NEMA34 integrated stepper motors are UL / cUL approved for the USA and Canadian markets according to UL61800-5-1, CAN/CSA 22.2 (file number E254947). Customers are now assured that these JVL integrated steppers meet high-quality standards for electrical safety associated with UL and CSA certifications.
UL in Denmark and Italy have helped with the development to achieve new raw motors and electronics with special UL insulation. Four different stack sizes MIS340, MIS341, MIS342 and MIS343 have been developed. The motors can be used up to 60 VDC supply voltage with UL approval and up to 72 VDC for non-UL applications.
Many Different Shaft Versions
ServoStep™ in size NEMA34 have the most possibilities when it comes to shafts. Apart from the existing Ø9.53 mm and Ø14.0 mm as well as Double Shaft and Hollow Shaft (Inner Ø12 mm / Outer Ø15 mm) now you can also order a Ø12.7 mm shaft version.
Superior Speed Control
The onboard SMC85 controller has a market leading resolution of 409600 counts/rev which makes the motor run smooth at any speed in increments of 0.01 RPM. Furthermore all ServoStep™ can run up to 3000 RPM with high efficiency due to optimized current regulation.
The onboard SMC85 controller has a market leading resolution of 409600 counts/rev which makes the motor run smooth at any speed in increments of 0.01 RPM. Furthermore all ServoStep™ can run up to 3000 RPM with high efficiency due to optimized current regulation.
All-in-one unit
ServoStep™ has everything built-in including motor, encoder, drive electronics, control electronics with ePLC™ and optional Ethernet or CAN bus integrated into one compact unit. All major industrial Ethernet protocols like Profinet, EtherNet/IP, EtherCAT, SERCOS, ModbusTCP/UDP and Powerlink are available.
Options include absolute multiturn encoders and STO (safe torque off, SIL3).
Also included are 8 I/O points which can be individually configured as digital input or output – or analogue input. The IOs can be used as local/remote IOs for the central PLC – or used together with the ePLC™ in stand-alone applications.
ServoStep™ has everything built-in including motor, encoder, drive electronics, control electronics with ePLC™ and optional Ethernet or CAN bus integrated into one compact unit. All major industrial Ethernet protocols like Profinet, EtherNet/IP, EtherCAT, SERCOS, ModbusTCP/UDP and Powerlink are available.
Options include absolute multiturn encoders and STO (safe torque off, SIL3).
Also included are 8 I/O points which can be individually configured as digital input or output – or analogue input. The IOs can be used as local/remote IOs for the central PLC – or used together with the ePLC™ in stand-alone applications.
Ethernet Switch for Daisy-Chain Connection
You can choose between all major Ethernet protocols and due to the built-in Ethernet switch you can connect all your motors with just one cable running between them.
You can choose between all major Ethernet protocols and due to the built-in Ethernet switch you can connect all your motors with just one cable running between them.
Function blocks (FB) for Siemens PLCs and Add-On-Instruction (AOI) for Rockwell Allen Bradley ControlLogix PLCs are available for download.
Additionally, each motor can be equipped with an IO Junction Box for collecting sensor inputs or trigger outputs.
Additionally, each motor can be equipped with an IO Junction Box for collecting sensor inputs or trigger outputs.
|
Key features
|
 |
Read more about MIS34 here: MIS34
Read more about JVL´s Integrated Stepper Motors here: MIS - Integrated Stepper Motor
Read more about JVL´s Integrated Servo Motors here: MAC - Integrated Servo Motor
